ClayTech PROSUB C9 - Drainage Pump 9m Head 195L/Min

Order Code: 807695

Print
Product Code
CLA-PROSUB-C9
RRP: $440.00 incl. GST
Find Your Nearest Store
Technical Specifications
Brand ClayTech Pumps
Pack Weight (KG):
6.00
Features
Filtered Grey Water Pump

The perfect compact pump for grey water applications like domestic washing machine water. Features an integrated float switch and simple flick of a switch for automatic to manual.

Why this pump?

Used for screened grey water applications, like domestic washing machine water. The float switch is integrated into the pump body allowing it to operate in small tanks or pits. Switching from automatic to manual is as simple as flipping a switch allowing water to be removed down to a depth of 3mm.

Normal operation switch on at 115mm and off at 50mm.

Technical Data
ClayTech ProSub C6 Technical Data
Power Absorbed (w) P2250
Max Head9m
Pump Max Flow Rate195 L/min
Pump Outlet Size1ΒΌ"
Pump Diameter215mm
Pump Height320mm
Max Solids Handling5mm
Downloads
Product Information and Data Sheets
Download Product Information & Data Sheets v1.0
Spare Parts Information and Exploded Diagrams
Download Spare Parts Information & Exploded Diagrams v1.0
