BIA-C3280-180 - BIANCO HOT WATER CIRCULATOR

Order Code: 805645

Print
Product Code
BIA C3280-180
RRP: $990.00 incl. GST
Find Your Nearest Store
Technical Specifications
Brand Bianco Pumpz
Product Type Circulator Pump
Suitable For Solar Hot Water
Flow Range Category b. 100 - 199 L/min
Flow Rate (L/min) 134
Head Range Category a. 0 - 39 m
Max Head (m) 8 m
Port Size Outlet 2" BSPM outlet
Volts 240 V
Warranty (months) 24 Months
Pack Weight (KG):
6.00
Description
This is a pump used for domestic hot water circulating. The Stainless steel housing makes it suitable for underfloor heating. It is maintenance free and is low in noise. Comes complete with 2" F x 1-1/4" F unions.
Features
The pump is characterised by:
  • Circulation body materials suitable for potable water
  • 3 speed operation
  • Flows to 134 l/min
  • Heads to 8m

Liquid temperature: 2OC - 110OC
Materials: Pump body: Stainless Steel 304 SS
Impeller: Corrosion resistant composite PPO
Back Plate and Rotor Can: Stainless Steel 304 SS
Unions: 2" F x 1-1/4"F Unions Stainless Steel 304 SS

Installation: Maximum ambient temperature: 40OC
Maximum Operating Pressure: 10 bar
Port spacing: 180mm
Port size: 2” BSPM (1-1/4” BSPF if used with supplied unions)

Electrical Data: 230V
Mains Frequency: 50Hz
Power consumption speeds: 1,2,3
135W 190W 245W
Motor: Continuous
Motor type: Canned rotor
Ingress Protection: IP44
Power cable: 1m
